120-Gallon Dual-Stage Electric Simplex Compressor – Aes-20315-120Hm

Description

AES-20315-120HM

AES M Series – 15.0 HP Simplex Horizontal

Loaded with standard features, the M Series air compressors are available in many motor configurations. Offered with vertical or horizontal tank options, this series comes complete to meet the most demanding industrial applications.

Compressor Pump: Splash lubricated · Stainless steel braided discharge hose · Large canister intake filter · Oil lever sight indicator

Motor: Industrial low RPM motor · Magnetic start for thermal overload protection

Frame: Powder coated ASME coded 120-gallon receiver tank · 3/16-inch base plate to reduce vibration · Totally enclosed powder coated belt guard

Components: ASME safety valves · Tank pressure gauge · Hour meter · Large fly wheel · Intake filter/silencer · Tank shut-off valve

Specifications

• CFM @ 175

  46.5

• Horsepower/Motor

  15.0 HP, 200V, 3Ø, 44.0A

• Pump RPM

  990

• Compressor

  Two Stage, Cast Iron

• Tank Size

  120 gallon

• Bolt Down (LxW)

  34.5 x 23.5 in.

Weights & Dimensions

• Net Weight

  856.00 lbs.

• Shipping Weight

  935.00 lbs.

• Length

  74.00 in.

• Width

  26.50 in.

• Height

  58.00 in.

Limited Warranties:

• 1 Year Electric Motor
• 2 Year Pump Exchange
