20-Gallon Dual-Stage Gas Air Compressor – Am2-Ph09-20M

Description

AM2-PH09-20M

This model features a powerful and efficient two stage compressor designed to maximize productivity. The versatility of the 20-gallon air compressor offers extra air storage and comes in stationary or portable models.

Compressor Pump: Splash lubricated · Stainless-steel braided discharge hose · Large canister intake filter · Oil level sight indicator

Frame: Powder coated ASME coded 20-gallon receiver tank · 3/16-inch base plate to reduce vibration · 14-gauge powder coated two-piece belt guard · 13-inch flat-free tires

Components: Regulator and two gauges for tank and outlet pressure · Manual drain valves for proper maintenance · 16 1/2-inch fly wheel · Quality pilot valve unloader

*Equipped with 150-PSI maximum rated regulator

Specifications

• CFM @ 175 PSI*

  17.2

• Displacement/ Engine

  270cc Honda GX270 OHV

• Compressor

  Two Stage, Cast Iron

• Tank Size

  20 gallon

• Engine Idle Control

  Pneumatic

Weights & Dimensions

• Net Weight

  306.00 lbs.

• Shipping Weight

  356.00 lbs.

• Length

  46.00 in.

• Width

  26.00 in.

• Height

  39.50 in.

Options

• AX-0003 Manual Drain/Regulator/Metal Bowl

  Drains moisture from air system

• AX-0015 Electric Start – Battery and Cables Not Included

  For easy starting

• IX-0055 Remote Start/Choke

  Remote start/choke; 6-foot wire extension for key switch; you will also need to order electric start option, AX-0015

• IX-0059 Remote Start/Choke

  Remote start/choke; 6-foot wire extension for key switch, sealed cable; you will also need to order electric start option, AX-0015

• AX-0017 Electric Start – Sealed Battery and Cables Included For easy starting

Limited Warranties:

• 2 Year Pump Exchange
• 3 Year Honda Engine

View Product Sheet
