Binks Low-Shear Back Pressure Regulator — 1½" Pilot-Controlled (Series 107755-X-X) 1

Binks Low-Shear Back Pressure Regulator — 1½” Pilot-Controlled (Series 107755-X-X)

Price range: $92.28 through $92.66

Quantity
SKU: N/A Category: Brand:

Description

Back Pressure Regulator (Low Shear 1½”) Series 107755-X-X Pilot Control

Manufacturer: Binks

Part Number: 107755-X-X

Description: The Binks Low Shear range of back pressure regulators use either operator set spring pressure (107754-X-X) or air pressure (107755-X-X) to control system fluid pressure upstream of the device by automatically adjusting the level of restriction applied to the flow of fluid passing between its inlet and outlet ports. For system pressure regulation at flow rates below the minimum shown, consider the smaller (¾”) product range based on 107757 (manual spring control) and 107758 (air control).

Specifications:

107755-X-X Pilot Control
Ideal Working Range 1-15 bar
10-100 l/min
Max. Static Pressure  25 bar
Wetted Material 303 grade stainless steel, PTFE, TFM
Weight kg (lb) # 7.5 (16.5)


Literature:

  • Manual

Explore more from our collection.

Additional information

Back Pressure Regulator Model 107755 Fittings

2" Sanitary – Inlet / Outlet (Model 107755-B-B), 1 ½" Sanitary – Inlet / Outlet (Model 107755-C-C), 1 ½" NPT Female – Inlet / Outlet (Model 107755-D-D), 2" Sanitary – Inlet / Outlet (Model 107755-M-M) 272mm Length
