Description
2011-2016 Ford F250-F350 4wd 4in. Radius Arm Lift Kit| rear leaf spring| Diesel engine – Fox 2.5 FRS DSC coilover front shocks with Fox 2.0 Performance Series Dual Shock| Fox 2.0 Performance Series rear shocks
Specifications:
| Description_ASC | Removal of factory block required. Rear add a leaf is required for models equipped with factory 3-7/8″ block for the level to tail high stance. Single add-a-leaf kit # 113218 recommended for more level stance – Dual add-a-leaf kit # 113209 recommended for tail high stance. (Add-A-Leafs do not apply to rear leaf spring-equipped systems) |
| Description_ASC | If equipped with a 2-piece driveshaft a driveshaft alignment kit (#123402) may be required. |
| Description_ASC | Although extremely rare front and/or rear driveline vibration may occur. |
| Description_ASC | If equipped with a rear sway bar #123009 is required. |
| Description_ASC | U-bolts will not work on dually. |
| Description_DES | 2011-2016 Ford F250-F350 4wd 4in. Radius Arm Lift Kit| Diesel engine |
| Description_EXT | 2011-2016 Ford F250-F350 4wd 4in. Radius Arm Lift Kit| rear leaf spring| Diesel engine – Fox 2.5 FRS DSC coilover front shocks with Fox 2.0 Performance Series Dual Shock| Fox 2.0 Performance Series rear shocks |
| Description_FAB | FOX 2.5 Coil-Over mounts in factory coil bucket location |
| Description_FAB | Adds additional secondary FOX 2.0 shock for max performance |
| Description_FAB | Eibach coil springs ride smooth through the roughest terrain |
| Description_FAB | Heavy duty tubular steel radius arms that correct caster while maximizing ground clearance |
| Description_FAB | Track bar relocation bracket and pitman arm maintain proper steering angles for improved handling |
| Description_FAB | Fabricated steel blocks provide level stance from front to rear |
| Description_FAB | FOX shocks are fully serviceable and resistant to corrosion and harsh environments |
| Description_MKT | Built to outperform upgrade your 2011-2016 Ford F250 and F350 Super Duty diesel powered truck with this 4-inch radius arm lift kit and FOX 2.5 Coil-over conversion from BDS Suspension. Designed to improve stance performance and capability this kit includes everything necessary to set your truck up right with clearance for up to 35″ tires. |
| Description_MKT | To optimize steering geometry once lifted a forged drop pitman arm is used to minimize the steering angle and pair it with a heavy duty track bar drop bracket to keep them in phase through suspension travel while recentering the front axle. |
| Description_MKT | Up front the lift kit includes diesel-specific FOX 2.5 coil-over shocks heavy duty replacement radius arms forged drop pitman arm and track bar bracket for steering correction sway bar relocation and brake line brackets. |
| Description_MKT | In the rear this kit utilizes a high-strength fabricated lift block u-bolt flip kit for max ground clearance brake line brackets and a matching set of FOX Performance shocks. |
| Description_MKT | FOX 2.5 Coil-Over Conversion |
| Description_MKT | FOX 2.5 coil-overs offer next level performance for on-road comfort and off-road comfort capability. Tuned and ready to install right out of the box these bolt-on 2.5-inch diameter coil-overs are built for abuse and packed with race-proven technology. They include a remote reservoir for additional fluid capacity to keep your shocks running cool so you can push the limits in the rough terrain. |
| Description_MKT | HD Radius Arms |
| Description_MKT | In place of the factory stamped steel radius arms BDS supplies a pair of high-strength tubular radius arms. These arms mount into the factory location and offer caster adjustment for a wide range of lift heights along with an OE-style rubber bushing at the frame mount for smooth quiet service-free operation. |
| Description_MKT | Steering Correction |
| Description_SHO | Suspension lift kit |
| Description_DEF | Suspension Lift Kit |
